Enamel/enamel coating equipment production line/sandblasting, coating, drying, sintering production line/fully automatic enamel steel pipe production line
2023.05.25

 Pretreatment

       In order to achieve the purpose of enamel anti-corrosion, the porcelain layer must be tight, free of voids, and have strong adhesion to the underlying steel. For this reason, it is necessary to clean and pre-treat the steel.

There are two pre-treatment methods: chemical method and physical method.

Most manufacturers who choose physical methods use sandblasting technology. Sand blasting can not only clean the surface, but also make the surface rough, which is conducive to increasing the tightness of the ceramic layer and steel surface. The factors to be considered when selecting the sand blasting method include surface stains, surface roughness, and economy.

Chemical cleaning usually uses the acidic method. For steel, sulfuric acid is usually used for cleaning. For bimetallic metals such as aluminum, alkaline solutions (such as NaOH) are usually used for cleaning. After cleaning, the steel must be cleaned with water to remove the residual acid solution.

 Enameling

There are usually two types of coating for conventional water heaters: wet method and dry method.

The wet process mainly includes spraying, immersion coating, and rolling coating methods. By rotating the inner liner in three-dimensional space, all internal surfaces are coated with glaze. Excess residue and liquid must be removed to ensure that the steel surface is only covered with a thin, uniform, and continuous layer of glaze. There are many factors that affect the quality of enamel, such as the viscosity of the glaze, the pre-treatment of steel, the adhesion of the metal surface, the quality of welding, and the structure of the inner liner. Wet coating is more popular in the United States.

The main drying method is electrostatic spraying. Electrostatic spraying has many advantages compared to wet systems. It reduces costs, saves energy, and achieves a material utilization rate of 97%. In addition, it also reduces pollution to the environment. At present, some large water heater manufacturers in Europe mostly use electrostatic spraying method.

Most water heater manufacturers only spray one layer of enamel. Only for applications with more stringent temperature and pressure conditions, such as water tanks, two layer spraying is used. Some use a special pre coating to cover the enamel.

Enamel firing

      At 700 ℃, the enamel begins to melt and form a ceramic layer. The baking temperature is generally maintained between 830-860 ℃, with a duration of 7-15 minutes. The reddened inner liner is removed from the furnace and gradually cooled to room temperature. Usually, the enamel firing process is continuous and can be repeated again to form a second layer of enamel. Even repeated multiple times to obtain the multi-layer enamel required under harsh application conditions.

GGH Enamel Enamel Steel Pipe Automatic Coating, Drying, and Sintering Production Line

Fully automatic enamel steel pipe (including pre-treatment coating, coating, drying and sintering) production line

Enamel high-temperature sintering furnace

Water heater liner sandblasting and coating system equipment

Inner liner powder spraying equipment

Tunnel type enamel sintering furnace

Water heater liner sandblasting and coating system equipment
